P2.5mm Indoor SMD 160mmx160mm 1/32 Scan LED Module

    P2.5mm Indoor SMD 160mmx160mm 1/32 Scan LED Module
    Roll over image to zoom in
    Click to open expanded view

    $16.00

    In stock

    P2.5mm Indoor LED Display Module for LED screen repair, replacement, and new display projects. Check pitch, size, scan mode, brightness and fast global shipping from REILED.

    Wishlist
    Categories: , , Tags: , , ,

    P2.5mm Indoor SMD 160mmx160mm 1/32 Scan LED Module

    Indoor P2.5mm SMD LED Display Module Size is 160mmx160mm With 64×64 dots.

    Attention:

    • We recommend that you buy the same batch led modules at once for the Same LED Display. Because different batches of led modules have different brightness and display colors, even different config files.
    • If you want to build led screen, please buy enough LED Modules and Spare Parts.
    • Tariffs or Duties at the destination not included. If you have questions about Importation to your country, please contact us online sales.

    Remark:

    • LED Module including the Data & Power Cables.
    • 2 Years Warranty, Ship in 24 hours, Free Online Support.
    • LED Module Can Work With Linsn, Novastar, Colorlight, Xixun LED Conrol Card Etc.
    • 72 Hours aging test (white balance aging (2×24 hours) and video aging (24 hours)) before dispatch.

    Main Specifications:

    Resolution64(H)×64(V)
    Pitch2.5mm
    LED ArrangementSMD2121
    Driver ModeDynamic 1/32 Duty constant current
    Size160mm×160mm
    MaskPure Black mask-high contrast screen
    3.Electricity Parameter
    Optical Ratings
    Brightness≥1000cd/㎡
    View Angle140 degree ( horizontal)  140degree(vertical)
    View Distance2.5m-25m
    Gray Scale8bits input, correction with 16bits
    Display Color16.7M
    Brightness Adjustment100 levels
    Power Supply
    Operation PowerAC100-240V 50-60HZ  Switch-able
    Maxim Power Consumption700 W/m2
    Average Power Consumption300 W/m2
    Control System
    Correction Scale Level16bits
    Frame Update Frequency60Hz
    Screen Refresh Frequency480-960Hz
    Gamma Correction-5.0—5.0
    Support InputComposite Video, S-Video, DVI, HDMI., SDI, HD_SDI
    Control DistanceEthernet cable 100m, optical fiber 5km
    Support VGA Mode800×600,1024×768,1280×1024,1600×1200
    Color Temperature5000-9300 adjustable
    Brightness Correctiondot by dot, module by module, cabinet by cabinet
    Reliability
    Operating Temp.-20-60 Celsius degree
    Operating Humidity10-95% RH
    Operating Life100,000 hours
    MTBF5000 hours
    Continuous Working Time≥48 hours
    Protection LevelIP54
    Out of Control Pixel Rate0.01%

    P2.5mm Indoor LED Display Module for LED Display Projects

    The P2.5mm Indoor LED Display Module is suitable for LED module replacement, display repair, spare-part stocking, and new LED screen assembly. It helps buyers compare specifications and select a compatible part before ordering.

    Before purchase, confirm pixel pitch, module size, scan mode, connector position, brightness, and indoor or outdoor application. REILED can help check your LED module, cabinet, receiving card, power supply, or control system configuration before shipment.

    Before You Order

    • Confirm the exact model, pitch, size, or control system requirement.
    • Check connector layout and installation position against your existing screen.
    • Keep spare parts ready for repair, rental jobs, and urgent maintenance.

    Additional information

    Product Dimensions
