    P10mm Outdoor DIP 160mmx160mm LED Module

    Outdoor P10mm DIP LED Display Module Size is 160mmx160mm With 16×16 dots.

    Attention:

    • We recommend that you buy the same batch led modules at once for the Same LED Display.Because different batches of led modules have different brightness and display colors,even different config files.
    • If you want to build led screen,please buy enough LED Modules and Spare Parts.
    • Tariffs or Duties at the destination not included.If you have questions about Importation to your country,please contact us online sales.
    P10  160×160 DIP Specification
    LED ModuleLINSN-P10-Outdoor-16X16-DIP
    Resolution16(W) * 16(H)
    Pixel Pitch10 mm
    LED ArrangementDIP346, 1R1G1B
    Module Size160mmx160mm
    Driver Mode1/4 Scan
    Protection GradeIP65 Waterproof
    Brightness6500 – 6800 nits
    Electricity Parameter
    Working VoltageDC 5V
    Power SupplyAC 110 / 220V, 50/60Hz
    Maxim Power Consumption15 W
    Density10000 pixels/m2
    Viewing Angle120 degree (horizontal & vertical)
    Viewing Distance10m – 100m
    Working Temperature16bit
    Color Processing5000 — 9500 (choice by user)
    Color Temperature(k)≤ 1mm juncture
    Whole Display Flatness-20°C ~ +50°C
    Refresh Frequency≥960HZ
    Humidity(RH)≤ 90 ~ 95%
    Screen Lifetime100000 hours
    Warranty Time2 Years
    CertificatesCE,RoHS

    High Quality LEDs:

    High-Quality 1R1G1B LED Display Module are equipped with data cables and power cables and 2 Years Warranty, All Outdoor LED panels with high brightness and color uniformity to ensure the LED display has excellent visual performance.

    72+ Hours Aging

    72 Hours aging test (white balance aging (2×24 hours) and video aging (24 hours)) to improve the reliability of the outdoor LED display panels.

    P10mm Outdoor LED Display Module for LED Display Projects

    The P10mm Outdoor LED Display Module is suitable for LED module replacement, display repair, spare-part stocking, and new LED screen assembly. It helps buyers compare specifications and select a compatible part before ordering.

    Before purchase, confirm pixel pitch, module size, scan mode, connector position, brightness, and indoor or outdoor application. REILED can help check your LED module, cabinet, receiving card, power supply, or control system configuration before shipment.

    Before You Order

    • Confirm the exact model, pitch, size, or control system requirement.
    • Check connector layout and installation position against your existing screen.
    • Keep spare parts ready for repair, rental jobs, and urgent maintenance.
