Meanwell 100W Power LPV-100-24

Meanwell 100W Power LPV-100-24
Roll over image to zoom in
Click to open expanded view

$24.50

In stock

MEANWELL LPV-100-24 24V 4.2A / 100W constant-voltage LED power driver with IP67 encapsulated plastic case.

Wishlist
SKU: LPV-100-24 Categories: , , , , Tags: , , Brand:

Specifications

ManufacturerMEANWELL
ModelLPV-100-24
Output24V 4.2A 100W
Input voltage range90-264VAC / 127-370VDC
Frequency47-63Hz
Efficiency85%
ProtectionsShort circuit / overload / over voltage
Working temperature-25 to +70°C
Ingress protectionIP67
Size190 × 52 × 37mm
Weight0.63kg

Ordering Check

  • Confirm the exact model number, voltage and connector/interface before replacing an existing part.
  • For LED modules, use the same batch for one screen whenever possible.

Additional information

Weight0.7 kg
Dimensions19 × 5.2 × 3.7 cm
Manufacturer

MEANWELL

Model

LPV-100-24

Output

24V 4.2A 100W

Input voltage range

90-264VAC / 127-370VDC

Frequency

47-63Hz

Efficiency

85%

Protections

Short circuit / overload / over voltage

Working temperature

-25 to +70°C

Ingress protection

IP67

Size

190 × 52 × 37mm

Weight

0.63kg
