DOOH RL-1 series

Pixel Pitch: P10mm DIP/15.6mm DIP

✔ ️ IP65 Water Proof
✔ ️ High Brightness
✔ ️ Energy Saving With Low Consumption
✔ ️ Easy Maintenance
✔ ️ Wide View Angles
✔ ️ Customizable Cabinet Dimensions As Needed
✔ Applications:
✔ Buildings, Restaurant, Hotel, Bank, Hospital, Station, Airport, Gym, Stadium, Store, Shop, Plaza, Parking Lot, Park, Pole structure, Column structure, Church etc.

Customized New LED Display Solutions for You

High compatibility

High compatibility for SMD and DIP, customizable enclosure size to meet varying project dimensions from P2.5, P3, P3.33, P4, P5, P6.66, P8 to P10. Catering to a range of settings, and fulfilling a wide array of installation requirements. Our well designed and finished cabinet seamlessly connects individual units without any visible gaps. Its sturdy design keeps the screen smooth and free from distortion.

Energy saving solution

REILED outdoor fixed installation LED display offers an outstanding visual experience with ultra-low power consumption and minimal heat generation, leading to cost savings.

LED diplays we built recently

SPECIFICATION

Specification
Pixel Pitch	P2.5mm	P3mm	P3.33mm	P4mm	P5mm	P6.66mm	P8mm	P10mm
LED Types	Outdoor SMD1415	Outdoor SMD1921	Outdoor SMD1921	Outdoor SMD1921	Outdoor SMD1921	Outdoor SMD2727	Outdoor SMD3535	Outdoor SMD3535
Pixel Density:	160000/㎡	111111/㎡	90000/㎡	62500/㎡	40000/㎡	22500/㎡	15625/㎡	10000/㎡
Module Size : (W x H)	320*160mm	192*192mm	320*160mm	320160mm (256128mm)	320*160mm	320*160mm	320160mm (256128mm)	320*160mm
Module Resolution: (Pixels)	128 *64	128 *64	96*48	8040 (6432)	64*32	48*24	4020 (3216)	32*16
Module Scanning method :	1/16	1/16	1/12	1/10 (1/8 )	1/8	1/6	1/5 (1/4 )	1/4
Luminance of White Balance:	> 5500cd/㎡	> 5500cd/㎡	> 5500cd/㎡	>6000cd/㎡	> 6000cd/㎡	> 6500cd/㎡	> 6000cd/㎡	> 6500cd/㎡
Average Power Consumption:	270w/㎡	270w/㎡	270w/㎡	240w/㎡	240w/㎡	240w/㎡	240w/㎡	240w/㎡
Maximum Power Consumption:	900w/㎡	900w/㎡	900w/㎡	800w/㎡	800w/㎡	800w/㎡	800w/㎡	800w/㎡
Best Viewing Distance:	≥2.5m	≥3m	≥4m	≥4m	≥5m	≥7m	≥8m	≥10m
Cabinet Size : (W x H)	Outdoor standard cabinet size 960*960mm (Adjustable based on clients final screen size)
Cabinet Material:	Outdoor Aluminum/ Steel / Die-cast aluminum
IP Rate:	IP65 Front /IP54 Rear
Cabinet Weight:	Aluminum / Die-cast aluminum 30kg/sqm , Steel 40kg/sqm
Maintenance Way	Back service
Viewing Angle:	H140°/V140°
Refresh Rate:	Basic 1920hz High 3840-5000hz
Grey Scale:	16bit
Input power	100-120V /200-240V
Operating Environment Temp.:	-20’~50 ℃
